Supreme Cattle Diet Feeders (Mixer Wagons)
The Supreme range of cattle diet feeders (mixer wagons) are a heavy duty option when it comes to feeding dairy and beef cattle. They mix up to 50% quicker than most tub feeders and offer a thorough mix for more accurate TMR management.
With the largest drive-train in the industry, AR200 steel (hardox), as standard, featuring on high wear sections along with Supreme's level of engineering they have earnt a name globally as a superior diet feeder.
Supreme has revolutionized the livestock feeding industry by adding many new innovative features to the vertical processor that enabled livestock producers to feed their cattle more efficiently allowing them to lower their feed costs and improve their gains.
Supreme has become the benchmark for quality throughout the world and the name Supreme has become synonymous with the performance and reliability.
"No matter what kind of bale is put in the Supreme, it cuts it to the quality we want. The machine mixes with superior accuracy and can blend anything. It's built like a tank, almost indestructible. We can feed a balanced ration where we can control our moisture, fiber, and energy and cut our feeding time in half. As soon as we went to TMR feeding we gained 5 liters per cow. We were able to dry up 15 cows and come up with the same amount of milk in the tank. Health wise we stabilized stomach upsets therefore having far less health problems with the herd. The Supreme has allowed us to manage the herd with a lot more time to be used in other areas instead of feeding. The machine is user friendly. It is so adaptable and simple it takes a minimal amount of effort to blend any ration. Horsepower requirements are very low as well."
Road Side Dairy, Alberta, Canada
Specifications
Supreme range in capacity from 6.7m3 to 53.1m3 with stated volume being that which is useable. The range is available as tractor pull-type, lorry-mounted or static.
Wagons can be fitted with either DG (Dinamic Generale) or Digistar weighing systems. Complete feed management programs are available from both manufactures that enable comprehensive tracking of rations, ingredients, loading accuracy, FCE or FCR (Feed Conversion Efficiency or Feed Conversion Ratio).
For nutritionists that are up to date with CV testing and Penn State Separator screening of TMR then Supreme equipment offers exceptional consistency from start to finish.
We offer 12 months beef or dairy nutrition, or we can work in with your exisiting nutritionist. This covers the Segue, Supreme and Enviro range.
We offer a service contract that is based on the number of cattle fed or throughput.
Warranty and Money Back Performance Guarantee
In conjunction with Supreme International we offer a money back guarantee on your purchase.The competition in the manufacturing and marketing of vertical feed processors is very aggressive and many manufacturers make inaccurate statements regarding capacity and performance of their products. It is because of this that we have created our performance guarantee. We stay with the truth and make no exaggerated statements. We understand that it can be difficult for a potential purchaser to find the truth and to be sure a manufacturer is accurate in their written or verbal statements. Supreme International has decided to put our money where our mouth is.
We are the first company to have a One-Year Money Back Performance Guarantee. We back our product with this performance guarantee and we will continue to research and to develop nothing but the best possible feed processors. We are committed to continue being the leader in Vertical Feed Processors. Supreme International
If you are potentially interested in a Supreme mixer please feel free to contact us on +44 7528 436 163 or by email at info@owencattle.com to discuss your requirements in more detail. We are happy to meet up on-farm as well to get a better understanding about expectations, buildings and financing options.
Calculating Capacity
Note: for your own calculations we have used the following formula to provide an approximate feeding potential of each diet feeder. Dairy cows consume a single TMR with nothing consumed in the parlour, 50kg fresh weight with a bulk density prior to feed out of 366kg/m3. The average cow in the UK and Ireland will be circa 7500-8000L per 305 days of lactation with a FCE (feed conversion efficiency) of 1.2-1.3 Therefore; 8000L/305D=26L/Day, FCE=1.2 results in 21.6kg of dry matter being consumed per day. A ration at 45 percent dry matter results in 48kg of fresh weight being fed per cow per day. We have rounded up to 50kg per cow per day.For the beef example a 500kg steer gaining weight will consume approximately 2.3 percent of its body weight per day in dry matter e.g. 500kg x 2.3 percent = 11.5kg/day in dry matter if ration is at 45-50 percent dry matter then 25kg of fresh weight would be consumed per head.
The Supreme International range (Supreme, Segue and Enviro) only quote useable volume.
Supreme 2000HDT (47.2-53.1m3)
Supreme_200HDT_triple_vertical_auger_cattle_diet_feeder.pdf
The Supreme 1600T will feed approximately 270-305 dairy cows (17.2-19.4t) or 600+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Three Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (3) Heavy-Duty, Hydrostatic Drive Motors with Horsepower Compensating Pumps
- 1000 rpm PTO
- Replaceable Forage Cutting Blades (15)
- Heavy-Duty Tubular Steel Frame
- Four Side Doors
- Ultra Wear Kicker Plates
- 1" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 6 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- Articulating Hitch
- (12) 11R22.5 Tyres and Hydraulic Brakes
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 1600T (37.5-41.9m3)
The Supreme 1600T will feed approximately 270-305 dairy cows (13.7-15.3t) or 600+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 10'(3.05m) Flat Conveyor
- Ultra Wear Kicker Plates
- 1" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (8) 275/70R 22.5 Truck Tyres with Walking Beam and Tandem Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 1400T (32.8-37.2m3)
The Supreme 1400T will feed approximately 240-270 dairy cows (12-13.6t) or 360+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 10'(3.05m) Flat Conveyor
- Ultra Wear Kicker Plates
- 1" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (8) 275/70R 22.5 Truck Tyres with Walking Beam and Tandem Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 1200T (26.4-30.4m3)
The Supreme 1200T will feed approximately 190-220 dairy cows (9.6-11.1t) or 360+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 10'(3.05m) Flat Conveyor
- Ultra Wear Kicker Plates
- 1" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (4) 11R/22.5, 16 Ply Truck Tyres with Budd Wheels and Heavy Duty Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 1000T (22.4-25.7m3)
The Supreme 1000T will feed approximately 160-180 dairy cows (8.2-9.4t) or 360+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 10'(3.05m) Flat Conveyor
- Ultra Wear Kicker Plates
- 1" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (4) 11R/22.5, 16 Ply Truck Tyres with Budd Wheels and Heavy Duty Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 900T (20.9-24.1m3)
The Supreme 900T will feed approximately 150-175 dairy cows (7.6-8.8t) or 200+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 8'(2.4m) Flat Conveyor
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (4) 11R/22.5, 16 Ply Truck Tyres with Budd Wheels and Heavy Duty Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 800T (18.4-21.3m3)
The Supreme 800T will feed approximately 130-150 dairy cows (6.7-7.8t) or 300+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 10'(3.05m) Flat Conveyor
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (4) 19 x 45 x 17 Floatation Implement Tyres with Walking Beam and Tandem Axle
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 700T (16.1-18.4m3)
The Supreme 700T will feed approximately 110-130 dairy cows (5.8-6.7) or 200+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 8'(2.4m) Flat Conveyor
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (2) 40 x 14.5 x 19 A/C Tyres or 385/65 R22.5 Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 600T (15.6-18.2m3)
The Supreme 600T will feed approximately 130 dairy cows (5.7-6.6t) or 260 (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 8'(2.4m) Flat Conveyor
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (2) 40 x 14.5 x 19 A/C Tyres or 385/65 R22.5 Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Month Nutrition Available
Supreme 500T (13.6-15.7m3)
The Supreme 500T will feed approximately 100-115 dairy cows (4.9-5.7t) or 230 (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Two Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- (2) Heavy-Duty, Two-Stage Planetary Drives
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Front Centre Door with 8'(2.4m) Flat Conveyor
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 4 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (2) 40 x 14.5 x 19 A/C Tyres or 385/65 R22.5 Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Month Nutrition Available
Supreme 600 (13.3-15.2m3)
The Supreme 600 will feed approximately 95-110 dairy cows (4.8-5.5t) or 200+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- Heavy-Duty, Two-Stage Planetary Drive
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (10)
- Heavy-Duty Tubular Steel Frame
- Left or Right Hand Side Door With Chute
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 3 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- Solid Truck Axle
- (4) 235 x 70 x 17.5 Truck Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 500 (11.3-13.1m3)
The Supreme 500 will feed approximately 80-95 dairy cows (4.1-4.8t) or 190+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- Heavy-Duty, Two-Stage Planetary Drive
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (5)
- Heavy-Duty Tubular Steel Frame
- Left or Right Hand Side Door With Chute
- AR200 Auger Kicker Plates
- 3/4" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 3 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- Solid Truck Axle
- (4) 235 x 70 x 17.5 Truck Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 400 (9.1-10.7m3)
The Supreme 400 will feed approximately 65-80 dairy cows (3.3-3.9t) or 160+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- Heavy-Duty, Two-Stage Planetary Drive
- 540 or 1000 rpm PTO
- Replaceable Forage Cutting Blades (4)
- Heavy-Duty Tubular Steel Frame
- Left or Right Hand Side Door With Chute
- AR200 Auger Kicker Plates
- 5/8" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 3 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (2) 19 x 45 x 17 Floatation Implement Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme 300 (6.7-7.9m3)
The Supreme 300 will feed approximately 50-60 dairy cows (2.4-2.9t) or 160+ (500kg) steers on a single TMR (total mixed ration) compiled by the Owen Cattle Company.
(Click on the image for pdf format)
Specifications
- Patented Freestanding Vertical Cutting Augers
- Manual Restrictor Plates
- Heavy-Duty Planetary Drive
- 540rpm PTO
- Replaceable Forage Cutting Blades (4)
- Heavy-Duty Tubular Steel Frame
- Left or Right Hand Side Door With Chute
- AR200 Auger Kicker Plates
- 5/8" M/S Floor
- 1/4" AR200 Walls
- 5/8" AR200 Lower Flight Auger Flighting
- Ultra Wear Kicker Plates
- Removable Heavy Duty Hitch Jack
- Ladder and Viewing Platform
- 3 pt DG Stad 04 Plus Scale wih Remote Port and 12 Recipe Programming Capability
- 12 Volt Battery
- (2) 12.5L-15, 12 Ply Rated Hwy Service Tyres
- 12 Month Warranty
- 36 Month Warranty on gearbox
- Service Contract Available
- 12 Months Nutrition Available
Supreme Diet Feeder Request Form
